12.1 Inch Touch Screen All In One PC With Intel Bay Trail Celeron J1900 Quad Core 2G RAM 64G SSD
12.1 Inch Touch Screen All In One PC With Intel Bay Trail Celeron J1900 Quad Core 2G RAM 64G SSD image 1
12.1 Inch Touch Screen All In One PC With Intel Bay Trail Celeron J1900 Quad Core 2G RAM 64G SSD image 2
12.1 Inch Touch Screen All In One PC With Intel Bay Trail Celeron J1900 Quad Core 2G RAM 64G SSD image 3
12.1 Inch Touch Screen All In One PC With Intel Bay Trail Celeron J1900 Quad Core 2G RAM 64G SSD image 4
12.1 Inch Touch Screen All In One PC With Intel Bay Trail Celeron J1900 Quad Core 2G RAM 64G SSD image 5

12.1 Inch Touch Screen All In One PC With Intel Bay Trail Celeron J1900 Quad Core 2G RAM 64G SSD

US $646.82 -7%

US $604.5

all in one pc



all in one computer

Editor Notes




Model Number:

Partaker Elite Z8

Screen Size:

12.1 Inch

Opening Hole Size:

297*235.5mm (Length*Width)

Screen Type:

Taiwan High Temperature 5 Wire Touch Screen

CPU:

Intel Core I7 Dual Core to 2.8Ghz

OS:

Windows Or Linux

RAM/SSD/HDD:

Maximum 8G RAM, 1* MSATA SSD+ 1* 2.5 Inch HDD

I/O:

4*USB2.0/2*RS232

I/O:

1*VGA/1*HDMI/1*RJ45

I/O:

1*DC/MIC-IN&LINE-OUT

Physical Dimension:

309.1*247.5*54(mm)

Gross Weight:

5KGS




Attributes




Opening Hole Size Drawing:








Features:

12.1 Inch LED Screen, 1024*768 Resolution

2mm slim panel, embedded design

Optional WiFi module, support for 802.11b / g / n

Support call on boot, network wake-up

Standard VESA screw hole, can choose the installation method flexibly

Support WinXP, Win7, Win8, Win10, Linux etc….







Panel Structure:

Panel Size

12.1 Inch LED Screen

Resolution

1024 × 768

Display Brightness

300cd/m(2)

Contrast

700:01:00

Response Time

12ms

Touch Screen

Using Taiwan imported 5-Wire high -temperature touch screen click life> 35 million times



Usage Environment:

Operating Temperature:

-10℃~60℃ Surface Air Flow

Operating Humidity:

10% ~ 95% @ 40 ℃ without condensation

Storage Temperature:

-20 ℃ ~ 70 ℃



Installation Method:

1. Embedded (Recommended)

2. Wall-mounted

3. Desktop

4. Cantilevered

5. Other Installation Methods



Motherboard:

BIOS:AMI 32Mbit,Support Diskless Start, Wake-Up on Lan, Call Boot (Power On Boot), Watchdog And Other Functions

Display Mode:Single Display; VGA+LVDS,HDMI+LVDS Synchronous / Asynchronous Dual Display

Motherboard:  Fan Design



I/O Interface:

Network: 1* Realtek 8111E 10/100/1000M Adaptive Network Card Chip

Audio: Realtek®ALC662 HD Audio Decoding Core
