Partaker Z9 13.3 Inch Touch Screen Computer Desktop With Intel Celeron C1037U 1.8Ghz
Partaker Z9 13.3 Inch Touch Screen Computer Desktop With Intel Celeron C1037U 1.8Ghz image 1
Partaker Z9 13.3 Inch Touch Screen Computer Desktop With Intel Celeron C1037U 1.8Ghz image 2
Partaker Z9 13.3 Inch Touch Screen Computer Desktop With Intel Celeron C1037U 1.8Ghz image 3
Partaker Z9 13.3 Inch Touch Screen Computer Desktop With Intel Celeron C1037U 1.8Ghz image 4

Partaker Z9 13.3 Inch Touch Screen Computer Desktop With Intel Celeron C1037U 1.8Ghz

US $442





  • 13.3 inch LED all in one touch panel pc with Made-In-China 4 Wire Resistive Touch Screen. Typical 1280*800 resolution. Compact, fully functional,all the power and functionality of a desktop computer in a all in one design,powered by intel celeron 3855u processor, ideal for industrial and commercial applications. suit for multiple application,industries, car repair shops, security, factory, business, fanancial and projects.



  • (Barebone, Single RAM/SSD/SSD+HDD without system).Others with Windows 7/10 pro as the default system, and linux ubuntu do need to leave us message on the order, thank you. hardware compatible with all windows/linux distributions.



  • Low power consumption, low heat, use dedicated turbo silent cooling fan to ensure long-term operation and stable heat dissipation. very slim, can stand on desk or embeded/mountable.



  • Designed with 3*RS232+VGA+LAN+3*USB2.0+1 USB 3.0+DC+Audio In &Out,aesthetic design and reasonable interface layout.



  • Size at 318*223.7*44.7(mm),6kgs,with power cord,auto power-on option could be customized,all use big brand memory and ssd/hdd with quality assurance.



  •



13.3 Inch All In One PC Touch Screen Computer Intel Dual Core Celeron 3855U Made-In-China 4 Wire Resistive Touch Screen



system



 4G RAM 64G SSD






if need other configuration, please pay extra cost via below Upgrade link
Upgrade service
How to upgrade?
1. Click Upgrade Link
2. For example, you need 4GB 64GB, the price is $420-$485=$35
3. Upgrade value, 1pc=$1
4. So you can buy 35pcs $1, and leave message for the configuration you need, Done.
systemDescription



Model Number: Partaker Z9

Screen Size: 13.3 Inch

Opening Hole Size: 280*194mm (Length*Width)

Screen Type: Made-In-China 4 Wire Resistive Touch Screen

CPU: Intel Celeron Processor 3855U (2M Cache, 1.60 GHz)

OS: Support Windows 7/8/8.1/10,WES7/8,Linux, Vxworks etc; (Barebone, Single RAM, Single SSD or SSD+HDD without any system). Others with Windows 7 pro as the default option, and linux ubuntu or Windows 10 pro do needs to leave us message on the order, thank you.

RAM/SSD/HDD: Maximum 8G RAM, 1* MSATA SSD+1*2.5 Inch HDD

I/O: 3*RS232+VGA+LAN+3*USB2.0+1 USB 3.0+DC+Audio In &Out

Physical Dimension: 318*223.7*44.7(mm)

Gross Weight: 6KGS

Features:

1: 13.3 Inch LED Screen, 1280*800 Resolution

2: Stable performance, support 7 * 24 hours of uninterrupted operation

Display Brightness: 250cd/m(2)

Contrast: 600 : 1

Response Time: 5ms

Touch Screen: Resistive touch screen

Usage Environment:

Operating Temperature: -10℃~60℃ Surface Air Flow

Operating Humidity: 10% ~ 95% @ 40 ℃ without condensation

Storage Temperature: -20 ℃ ~ 70 ℃

Installation Method:

1: Embedded (Recommended)

2: Wall-mounted

3: Desktop

4: Cantilevered

5: Others

BIOS: AMI 32Mbit,Support Diskless Start, Wake-Up on Lan, Call Boot (Power On Boot), Watchdog And Other Functions

Motherboard: Fan Design

Network: 1* Realtek 8111E Gigabit

Audio: ALC662

Package Size: 38CM(L)*30CM(W)*12.5CM(H)

Physical Weight: 2.8KG / 3.5KG(Net/Gross)

Power Supply: Input: 180-240V~1.0A 50-60Hz Output: 12VDC 4A MAX

Power Cord: Power Cord*1

Touch Pen: Resistance touch pen*1

Buckle: Embedded Installation Buckle* 1 Set







Model Number:

Partaker Elite Z9

Screen Size:

13.3 Inch

Opening Hole Size:

280*194mm (Length*Width)

Screen Type:

Made-In-China 4 Wire Resistive Touch Screen

CPU:

Intel Celeron 3855u Dual Core 1.6Ghz

OS:

Windows Or Linux

RAM/SSD/HDD:

Maximum 8G RAM, 1* MSATA SSD

I/O:

4*USB2.0/3*COM

I/O:

1*VGA/1*RJ45 (Dual RJ45 Optional, contact us for it)

I/O:

1*DC/MIC-IN&LINE-OUT

Physical Dimension:

318*223.7*44.7(mm)

Gross Weight:

6KGS











Opening Hole Size Drawing:










Features:

13.3 Inch LED Screen, 1280*800 Resolution

Stable performance, support 7 * 24 hours of uninterrupted operation

Exquisite appearance , It is light and with rich interface

Optional WiFi module, support for 802.11b / g / n

Standard VESA screw hole, can choose the installation method flexibly

Support WinXP, Win7, Win8, Win10, Linux etc….





Panel Structure:

Panel Size

13.3 Inch LED Screen

Resolution

1280*800

Display Brightness

250cd/m(2)

Contrast

600 : 1

Response Time

5ms

Touch Screen

Resistive touch screen







Usage Environment:

Operating Temperature:

-10℃~60℃ Surface Air Flow

Operating Humidity:

10% ~ 95% @ 40 ℃ without condensation

Storage Temperature:

-20 ℃ ~ 70 ℃





Installation Method:

1. Embedded (Recommended)

2. Wall-mounted

3. Desktop

4. Cantilevered

5. Other Installation Methods





Motherboard:

BIOS:AMI 32Mbit,Support Diskless Start, Wake-Up on Lan, Call Boot (Power On Boot), Watchdog And Other Functions

Display Mode:Single Display; VGA+LVDS Synchronous / Asynchronous Dual Display

Motherboard:  Fan Design







I/O Interface:

Network: 1* Realtek 8111E 10/100/1000M Adaptive Network Card Chip

Audio: Realtek®ALC662 HD Audio Decoding Core







Quality Inspection:

Each Partaker Industrial All In One Computer will conduct a number of strict testing, including performance testing, temperature testing, vibration, pressure, LED screen aging, interface testing, electronic load, touch screen detection

Before shipment, the appearance of Partaker Industrial All In One Computer, performance, interface, 24-hour aging test to ensure that each is superior quality.





Company Profile:

Focus on the industrial sector for 8 years, your most reliable suppliers

INCTEL Technology focus on All in One touch-screen, infrared touch All in One Computer, resistance touch All in One PC, advertising, touch products such as the development and production. For industrial control, commercial display, advertising, business meetings, games, entertainment, medical equipment and other fields, introduced a professional application solutions.







Package Information:

Package Size

38CM(L)*30CM(W)*12.5CM(H)

Physical Weight

2.8KG / 3.5KG(Net/Gross)

Power Supply

Input: 180-240V~1.0A 50-60Hz Output: 12VDC  4A MAX

Power Cord

Power Cord*1

Touch Pen

Resistance touch pen*1

Buckle

Embedded Installation Buckle* 1 Set










-_03-_04-_05  Additional



About Power Cord:

We will ship the type of power cord, based on your area.
